Attribute of Black Kapton Tape
| Attribute | Value |
|---|---|
| Brand | Fonitaniya |
| Serial Number | FON-10053 |
| Color | Matte Black |
| Total Thickness | 0.06 mm (0.00236 in) |
| Backing Thickness | 0.0125 mm (0.00049 in), 0.025 mm (0.00098 in) |
| Width | 3-500 mm |
| Length | 33 meters (108.27 ft) |
| Backing Material | Polyimide (PI) |
| Adhesive | Silicone |
| Peel Strength | 4-7 N/inch |
| Tensile Strength | 10-36 kg/25mm |
| Elongation | 30%-70% |
| Breakdown Voltage | 2.5-10.5 KV |
| Temperature Resistance (Long-Term) | Up to 260°C (500°F) |
| Temperature Resistance (Short-Term) | Up to 300°C (572°F) |
Black Kapton Tape for High Temperature
This Polyimide (PI) adhesive tape, also known as Kapton tape, is an industrial-grade solution designed for high-performance applications. Made from polyimide film with a silicone adhesive, it offers excellent thermal stability, electrical insulation, and chemical resistance, making it ideal for use in harsh environments. Withstanding temperatures up to 300°C (572°F), it’s perfect for demanding applications in electronics, aerospace, automotive, and more.
Commonly used in wave solder masking, component protection in electronic manufacturing, and insulation for motor coils, this tape provides reliable performance and leaves no residue upon removal. Its versatility makes it suitable for a range of tasks, including high-temperature insulation, anti-corrosive sealing, and custom die-cut applications for specific industrial needs.
Application
This polyimide adhesive tape is used for high-temperature insulation, wave solder masking, and component protection in electronic and industrial applications.
If you want to customize tapes of other specifications, you can contact us to customize the specifications you want.
When can I get my quotation?
We will provide you with a detailed quotation as soon as we receive your inquiry. Typically, we will send you a quote within 24 hours. If your requirements are complex or need custom services, it might take a bit longer, but we will keep you informed of the progress promptly.
What is your order schedule?
After confirming your order, we will schedule production based on your requirements and our production plan. Generally, the production cycle for standard orders is 2-3 weeks. If you have an urgent order, please contact us as soon as possible. We will do our best to accommodate your request and arrange expedited production.
Can I get samples?
Yes, we are happy to provide samples for you. Please contact our sales team with your specific needs and sample type, and we will arrange for the samples to be sent to you as soon as possible. Some samples may require a small fee, but in most cases, we offer free samples for testing and evaluation.
Can I print my logo on the tape?
Absolutely. We offer customization services and can print your logo on the tape according to your requirements. Please provide a high-quality logo file and specific printing requirements. Our design team will create a draft design for your approval. We will also provide samples for you to confirm before production.
What if I don't have detailed requirements?
If you are unsure about the specific requirements, our technical team is more than happy to offer professional advice. Just tell us your application scenario and basic needs, and we will recommend the most suitable tape solution based on our extensive experience and wide range of products. We can also provide sample testing to ensure our products meet your needs.
