Solar Encapsulant Film Fon-10026
- Dual Performance Flexibility: Available in two formulations, each option is engineered to deliver exceptional UV stability and optimum solar energy absorption.
- High Potential-Induced Degradation (PID) Resistance: Built to withstand PID effects, ensuring reliability and consistent performance in challenging environments.
- Strong Adhesion Properties: Excellent bonding strength to various substrates, promoting durability and stability in solar module assemblies.
- Seamless Integration: Compatible with existing lamination processes, providing a versatile solution for modern solar manufacturing.
Attributes to the Solar Power Tape Fon-10026
| Attribute | Dual Option EVA Encapsulant Film |
|---|---|
| Brand | Fonitaniya |
| Serial Number | Fon-10026 |
| Type | Ethylene Vinyl Acetate (EVA) |
| Thickness (Uncured) | 0.4 – 0.65 mm |
| Density (Uncured) | 0.92 g/cm³ |
| Tensile (Cured) | MD: 18 MPa / TD: 16 MPa |
| Elongation (Cured) | MD: 960% / TD: 810% |
| Adhesion to Glass | 100 N/cm |
| Water Absorption (Cured) | 0.12% |
| Electrical Volume Resistivity (Cured) | 1.1 × 10^15 Ω·cm |
| Optical Transmittance (Cured) | 93% / 92% |
| UV Cut Off (Cured) | 360 nm / 310 nm |
| MVTR | Not specified |
| Continuous Service Temperature | Not specified |
| Damp Heat Resistance (85% RH, 85°C, 1000h) | Δb* 1.0, ΔT% 1.8 / Δb* 0.6, ΔT% 1.5 |
| Features | High PID resistance, excellent UV stability / Increases power output, UV stability |
| Shelf Life | 6 months |
| Recommended Lamination Conditions | Temp: 145-155°C, Press: 8-13 min, Evacuation: 3-5 min |
Solar Power Tape Enhancement: Encapsulant Film Fon-10026
The Solar Encapsulant Film Fon-10026 is a versatile encapsulant solution that combines two advanced formulations of Ethylene Vinyl Acetate (EVA), tailored to meet diverse environmental and performance needs in photovoltaic (PV) module manufacturing. This film excels in providing enhanced UV stability and high resistance to potential-induced degradation (PID), ensuring optimal protection for solar cells in various applications.
Fon-10026 features outstanding adhesion properties, enabling it to bond effectively with multiple substrates, which significantly improves the durability and reliability of solar energy systems. The film’s compatibility with existing lamination processes facilitates seamless integration into production workflows, allowing manufacturers to enhance efficiency without major adjustments. With a transmittance rate of 93% and low water absorption, this encapsulant improves energy absorption and performance while safeguarding the solar cells.
Fon-10026 stands out as a superior alternative to conventional solar tape, maximizing the efficacy of solar power systems and contributing to the long-term reliability of solar modules. Incorporate Fon-10026 into your manufacturing process to ensure high-performance solar panels that meet industry standards.
Application
The Solar Encapsulant Film Fon-10026 is applied during the lamination of photovoltaic modules, encapsulating solar cells to provide protection against moisture and UV radiation. Its excellent adhesion properties enhance module durability and efficiency while seamlessly integrating into existing production processes.
If you want to customize tapes of other specifications, you can contact us to customize the specifications you want.
When can I get my quotation?
We will provide you with a detailed quotation as soon as we receive your inquiry. Typically, we will send you a quote within 24 hours. If your requirements are complex or need custom services, it might take a bit longer, but we will keep you informed of the progress promptly.
What is your order schedule?
After confirming your order, we will schedule production based on your requirements and our production plan. Generally, the production cycle for standard orders is 2-3 weeks. If you have an urgent order, please contact us as soon as possible. We will do our best to accommodate your request and arrange expedited production.
Can I get samples?
Yes, we are happy to provide samples for you. Please contact our sales team with your specific needs and sample type, and we will arrange for the samples to be sent to you as soon as possible. Some samples may require a small fee, but in most cases, we offer free samples for testing and evaluation.
Can I print my logo on the tape?
Absolutely. We offer customization services and can print your logo on the tape according to your requirements. Please provide a high-quality logo file and specific printing requirements. Our design team will create a draft design for your approval. We will also provide samples for you to confirm before production.
What if I don't have detailed requirements?
If you are unsure about the specific requirements, our technical team is more than happy to offer professional advice. Just tell us your application scenario and basic needs, and we will recommend the most suitable tape solution based on our extensive experience and wide range of products. We can also provide sample testing to ensure our products meet your needs.
