Teflon Glass Cloth Tpae
- Provides a non-stick, low friction surface on heat sealing and packaging equipment
- Performs under a wide range of temperatures, up to 572°F/300°C
- Silicone adhesive offers high temperature performance and long lasting durability
- Excellent chemical resistance, suitable for various challenging applications
Attributes of Fiberglass Teflon Cloth Tape
| Attribute | FON-10080-13 | FON-10080-18 | FON-10080-25 | FON-10080-30 |
|---|---|---|---|---|
| Total Thickness | 0.13 mm (5.12 mil) | 0.18 mm (7.09 mil) | 0.25 mm (9.84 mil) | 0.30 mm (11.81 mil) |
| Backing Thickness | 0.08 mm | 0.13 mm | 0.18 mm | 0.25 mm |
| Backing | Teflon Fiberglass Cloth | |||
| Adhesive Type | Silicone | |||
| 180° Peel Strength | 21 N/100mm | 22 N/100mm | 24 N/100mm | 24 N/100mm |
| Tensile Strength | 900 N/100mm | 1300 N/100mm | 1950 N/100mm | 2250 N/100mm |
| Long-Term Temp. Resistance | -70 – 260°C (-94 – 500°F) | |||
| Short-Term Temp. Resistance | -70 – 300°C (-94 – 572°F) | |||
| Color | Creamy White | Brown/Black | Brown/Black | Brown/Black |
Fiberglass PTFE High-temperature Cloth Tape
The Fonitaniya PTFE Glass Cloth Tape (Serial Number: FON-10080) is a premium-grade product reinforced with glass cloth backing and impregnated with PTFE. Known for its extremely low friction surface, this tape is perfect for providing a non-stick, low friction surface on various process machinery. The silicone adhesive ensures high temperature performance and long aging, making it suitable for a wide range of temperatures from -100°F to 572°F (-73°C to 300°C).
Designed for applications requiring high strength and durability, this tape resists tears, punctures, and many chemicals, making it ideal for heat sealing machines, ironing and pressing equipment, and mold release in composite bonding. Its excellent chemical resistance and very low moisture absorption allow it to perform effectively even in humid environments.
Application
General applications:
- Heat sealing machines: Provides a non-stick, heat-resistant surface.
- Ironing and pressing equipment: Ensures smooth operation and prevents sticking.
- High temperature bundling: Securely bundles items without degradation.
- Mold release in composite bonding: Facilitates easy release of molds in composite manufacturing.
- Separation barrier: Acts as a good barrier for the separation of dissimilar parts.
Electrical and electronic industry:
- Cable insulation and wrapping: Teflon tape is perfect for insulating and wrapping cables to prevent electrical leakage and ensure safe operation.
- Electronic component fixation: Use Teflon tape to secure electronic components such as resistors, capacitors, and IC chips during circuit board assembly, ensuring they remain in place even under vibration or impact.
- Circuit board insulation protection: Teflon tape covers sensitive parts of the circuit board to protect them from dust, moisture, or contaminants, ensuring optimal performance.
Chemical industry:
- Pipe and valve sealing: Effectively seals pipes and valves to prevent leaks of corrosive liquids or gases, ensuring production safety.
- Coating reactors and stirrers: Prevents chemical corrosion of equipment, extending the service life of reactors and stirrers by coating them with Teflon tape.
Construction sector:
- Fixing insulation materials: Ensures stability and sealing of insulation layers by fixing insulation materials such as insulation cotton, and insulation boards.
- Waterproof layer sealing: Enhances waterproofing in projects such as roofs and walls by sealing the joints of the waterproof layer.
Automobile industry:
- Engine and exhaust pipe sealing: Prevents leaks of oil, water, or other liquids, ensuring the normal operation of the engine.
- Car wiring harness wrapping: Protects wiring harnesses from wear and corrosion while improving electrical system safety by wrapping them with Teflon tape.
Aerospace field:
- Sealing and insulation of high-temperature components: Ensures the normal operation of aircraft like airplanes and rockets by providing sealing and insulation for high-temperature components.
If you want to customize tapes of other specifications, you can contact us to customize the specifications you want.
When can I get my quotation?
We will provide you with a detailed quotation as soon as we receive your inquiry. Typically, we will send you a quote within 24 hours. If your requirements are complex or need custom services, it might take a bit longer, but we will keep you informed of the progress promptly.
What is your order schedule?
After confirming your order, we will schedule production based on your requirements and our production plan. Generally, the production cycle for standard orders is 2-3 weeks. If you have an urgent order, please contact us as soon as possible. We will do our best to accommodate your request and arrange expedited production.
Can I get samples?
Yes, we are happy to provide samples for you. Please contact our sales team with your specific needs and sample type, and we will arrange for the samples to be sent to you as soon as possible. Some samples may require a small fee, but in most cases, we offer free samples for testing and evaluation.
Can I print my logo on the tape?
Absolutely. We offer customization services and can print your logo on the tape according to your requirements. Please provide a high-quality logo file and specific printing requirements. Our design team will create a draft design for your approval. We will also provide samples for you to confirm before production.
What if I don't have detailed requirements?
If you are unsure about the specific requirements, our technical team is more than happy to offer professional advice. Just tell us your application scenario and basic needs, and we will recommend the most suitable tape solution based on our extensive experience and wide range of products. We can also provide sample testing to ensure our products meet your needs.
